Input One s-video(Y/C),
1 Vpp @ 75 ohms (Y),
0.3 Vpp @ 75 ohms (C),
On a 4P connector
Output Three s-video(Y/C),
1 Vpp @ 75 ohms (Y),
0.3 Vpp @ 75 ohms (C)
On three 4P connectors
Video Bandwidth 430 MHz -3 dB
Video Signal-to-Noise Ratio More than 80 dB
Differential Phase 0.03°
Differential Gain 0.03%
Video Controls -0.8 dB to +6 dB (Y gain),
0.9 dB to +9.5 dB (Y EQ. @ 5.8 MHz),
-0.5 dB to +4.3 dB (Chroma gain)
Coupling AC
Dimensions 4.7 x 2.95 x 0.98" (WxDxH)
12 x 7.5 x 2.5cm (WxDxH)
Weight 0.67 lbs
.3 kg
Power Source 12 VDC, 40 amps
On a supplied AC adapter

• Modelo: KAMER 103YC
• 5 Unidades en Stock
• Fabricado por: KRAMER
