1 Pixel Pitch 10mm
2 Pixel configuration SMD 3 in 1
3 Size of module 160mm×160mm
4 Resolution of module 16 dots×16 dots
5 Size of cabinet 640mm×640mm
6 Resolution of cabinet 64 dots×64 dots
7 Cabinet material Aluminum cabinet for hanging and rental
8 Weight of cabinet 10KG
9 IP Grade Front IP65/Rear IP54
10 Density 10000 dots/㎡
11 Best viewing distance 12m
12 Best viewing angle >120°
13 Max power consumption ＜850 W / ㎡
14 Colors 16777216
15 Gray scale 14 bits
16 Color temperature 6500K
17 Control method Synchronous
18 Driving device constant current
19 Driving method 1/4 scaning
20 Frame frequence 60HZ
21 Refresh frequence 960HZ
22 Brightness 4000cd/ ㎡
23 Working voltage AC220V/110V±10%
24 Working temperature -10°c～45°c±10%
25 MTBF 10,000 hours
26 Leds Lifetime Up to 100,000 hours

• Modelo: 10 PITCH
• 5 Unidades en Stock
• Fabricado por: LED CONTACT
